[GH-ISSUE #3418] [Feature Request]内网https服务怎么代理出去 tcp https http2https 都试过了全都连不上 #2736

New issue

Closed

opened 2026-05-05 13:45:45 -06:00 by gitea-mirror · 6 comments

gitea-mirror commented

2026-05-05 13:45:45 -06:00

Owner

Originally created by @maogeigei on GitHub (Apr 21, 2023).
Original GitHub issue: https://github.com/fatedier/frp/issues/3418

Describe the feature request

试了以下三种方式都是500的错，还有那个frpc 配置里的remote_port 设置感觉没有作用，服务器查看对应端口也没有监听
[http2https]
type = tcp
custom_domains = 123.43.23.133
plugin = http2https
plugin_local_addr = 127.0.0.1:7800
remote_port = 6202

[tcp]
type = tcp
custom_domains = 123.43.23.133
local_ip= 127.0.0.1
local_port = 7800
remote_port = 6202

[web2]
type = https
custom_domains = 123.43.23.133
local_port = 7800

Describe alternatives you've considered

No response

Affected area

Docs
Installation
Performance and Scalability
Security
User Experience
Test and Release
Developer Infrastructure
Client Plugin
Server Plugin
Extensions
Others

Originally created by @maogeigei on GitHub (Apr 21, 2023). Original GitHub issue: https://github.com/fatedier/frp/issues/3418 ### Describe the feature request 试了以下三种方式都是500的错，还有那个frpc 配置里的remote_port 设置感觉没有作用，服务器查看对应端口也没有监听 [http2https] type = tcp custom_domains = 123.43.23.133 plugin = http2https plugin_local_addr = 127.0.0.1:7800 remote_port = 6202 [tcp] type = tcp custom_domains = 123.43.23.133 local_ip= 127.0.0.1 local_port = 7800 remote_port = 6202 [web2] type = https custom_domains = 123.43.23.133 local_port = 7800 ### Describe alternatives you've considered _No response_ ### Affected area - [ ] Docs - [ ] Installation - [ ] Performance and Scalability - [ ] Security - [ ] User Experience - [ ] Test and Release - [ ] Developer Infrastructure - [ ] Client Plugin - [ ] Server Plugin - [ ] Extensions - [ ] Others

gitea-mirror

2026-05-05 13:45:45 -06:00

closed this issue
added the
lifecycle/stale
label

gitea-mirror commented

2026-05-05 13:45:48 -06:00

Author

Owner

@Becods commented on GitHub (Apr 21, 2023):

@Becods commented on GitHub (Apr 21, 2023): ![CM6PHS7AGGJPN31Y2DI83MS](https://user-images.githubusercontent.com/35525491/233551388-2be38062-7be9-467c-9c92-de822753b68c.png)

gitea-mirror commented

2026-05-05 13:45:48 -06:00

Author

Owner

@superzjg commented on GitHub (Apr 24, 2023):

内网现存的https代理很简单啊，使用tcp和https都可以（不用http2https）
你的配置也有问题，用tcp时不需要写域名custom_domains，但要写远程端口remote_port；用https需要local_ip
使用时浏览器记得加https://

@superzjg commented on GitHub (Apr 24, 2023): 内网现存的https代理很简单啊，使用tcp和https都可以（不用http2https）你的配置也有问题，用tcp时不需要写域名custom_domains，但要写远程端口remote_port；用https需要local_ip 使用时浏览器记得加https://

gitea-mirror commented

2026-05-05 13:45:50 -06:00

Author

Owner

@github-actions[bot] commented on GitHub (May 25, 2023):

Issues go stale after 30d of inactivity. Stale issues rot after an additional 7d of inactivity and eventually close.

@github-actions[bot] commented on GitHub (May 25, 2023): Issues go stale after 30d of inactivity. Stale issues rot after an additional 7d of inactivity and eventually close.

gitea-mirror commented

2026-05-05 13:45:50 -06:00

Author

Owner

@shyandsy commented on GitHub (Dec 9, 2024):

@superzjg
尝试用tcp方式转内网https，不行啊

client端配置

[[proxies]]
name = "kubectl"
type = "tcp"
localIP = "192.168.101.20"
localPort = 6443
remotePort = 52000

服务端报错

2024-12-09 21:12:32.919 [I] [proxy/proxy.go:204] [b02c85b44184bf62] [kubectl] get a user connection [223.166.248.161:50422]
2024-12-09 21:12:32.919 [D] [server/control.go:272] [b02c85b44184bf62] get work connection from pool
2024-12-09 21:12:32.919 [D] [proxy/proxy.go:131] [b02c85b44184bf62] [kubectl] get a new work connection: [223.166.248.161:41344]
2024-12-09 21:12:32.919 [D] [proxy/proxy.go:261] [b02c85b44184bf62] [kubectl] join connections, workConn(l[172.16.19.89:50000] r[223.166.248.161:41344]) userConn(l[172.16.19.89:52000] r[223.166.248.161:50422])
2024-12-09 21:12:32.933 [D] [server/control.go:243] [b02c85b44184bf62] new work connection registered
2024-12-09 21:12:32.952 [D] [proxy/proxy.go:271] [b02c85b44184bf62] [kubectl] join connections closed

客户端没有任何log

@shyandsy commented on GitHub (Dec 9, 2024): @superzjg 尝试用tcp方式转内网https，不行啊 client端配置 ``` [[proxies]] name = "kubectl" type = "tcp" localIP = "192.168.101.20" localPort = 6443 remotePort = 52000 ``` 服务端报错 ``` 2024-12-09 21:12:32.919 [I] [proxy/proxy.go:204] [b02c85b44184bf62] [kubectl] get a user connection [223.166.248.161:50422] 2024-12-09 21:12:32.919 [D] [server/control.go:272] [b02c85b44184bf62] get work connection from pool 2024-12-09 21:12:32.919 [D] [proxy/proxy.go:131] [b02c85b44184bf62] [kubectl] get a new work connection: [223.166.248.161:41344] 2024-12-09 21:12:32.919 [D] [proxy/proxy.go:261] [b02c85b44184bf62] [kubectl] join connections, workConn(l[172.16.19.89:50000] r[223.166.248.161:41344]) userConn(l[172.16.19.89:52000] r[223.166.248.161:50422]) 2024-12-09 21:12:32.933 [D] [server/control.go:243] [b02c85b44184bf62] new work connection registered 2024-12-09 21:12:32.952 [D] [proxy/proxy.go:271] [b02c85b44184bf62] [kubectl] join connections closed ``` 客户端没有任何log

gitea-mirror commented

2026-05-05 13:45:50 -06:00

Author

Owner

@superzjg commented on GitHub (Dec 9, 2024):

@superzjg 尝试用tcp方式转内网https，不行啊

client端配置

[[proxies]]
name = "kubectl"
type = "tcp"
localIP = "192.168.101.20"
localPort = 6443
remotePort = 52000

服务端报错

2024-12-09 21:12:32.919 [I] [proxy/proxy.go:204] [b02c85b44184bf62] [kubectl] get a user connection [223.166.248.161:50422]
2024-12-09 21:12:32.919 [D] [server/control.go:272] [b02c85b44184bf62] get work connection from pool
2024-12-09 21:12:32.919 [D] [proxy/proxy.go:131] [b02c85b44184bf62] [kubectl] get a new work connection: [223.166.248.161:41344]
2024-12-09 21:12:32.919 [D] [proxy/proxy.go:261] [b02c85b44184bf62] [kubectl] join connections, workConn(l[172.16.19.89:50000] r[223.166.248.161:41344]) userConn(l[172.16.19.89:52000] r[223.166.248.161:50422])
2024-12-09 21:12:32.933 [D] [server/control.go:243] [b02c85b44184bf62] new work connection registered
2024-12-09 21:12:32.952 [D] [proxy/proxy.go:271] [b02c85b44184bf62] [kubectl] join connections closed

客户端没有任何log

可能跟网络环境有关，尝试改一下传输协议，比如frpc通用部分配置transport.protocol = "quic"，frps配置quic绑定UDP端口，并打开防火墙。印象中见过这种情况

也可不改协议尝试配置 transport.tls.disableCustomTLSFirstByte = false

@superzjg commented on GitHub (Dec 9, 2024): > @superzjg 尝试用tcp方式转内网https，不行啊 > > client端配置 > > ``` > [[proxies]] > name = "kubectl" > type = "tcp" > localIP = "192.168.101.20" > localPort = 6443 > remotePort = 52000 > ``` > > 服务端报错 > > ``` > 2024-12-09 21:12:32.919 [I] [proxy/proxy.go:204] [b02c85b44184bf62] [kubectl] get a user connection [223.166.248.161:50422] > 2024-12-09 21:12:32.919 [D] [server/control.go:272] [b02c85b44184bf62] get work connection from pool > 2024-12-09 21:12:32.919 [D] [proxy/proxy.go:131] [b02c85b44184bf62] [kubectl] get a new work connection: [223.166.248.161:41344] > 2024-12-09 21:12:32.919 [D] [proxy/proxy.go:261] [b02c85b44184bf62] [kubectl] join connections, workConn(l[172.16.19.89:50000] r[223.166.248.161:41344]) userConn(l[172.16.19.89:52000] r[223.166.248.161:50422]) > 2024-12-09 21:12:32.933 [D] [server/control.go:243] [b02c85b44184bf62] new work connection registered > 2024-12-09 21:12:32.952 [D] [proxy/proxy.go:271] [b02c85b44184bf62] [kubectl] join connections closed > ``` > > 客户端没有任何log 可能跟网络环境有关，尝试改一下传输协议，比如frpc通用部分配置`transport.protocol = "quic"`，frps配置quic绑定UDP端口，并打开防火墙。印象中见过这种情况也可不改协议尝试配置 `transport.tls.disableCustomTLSFirstByte = false`

gitea-mirror commented

2026-05-05 13:45:51 -06:00

Author

Owner

@yogaxu commented on GitHub (Nov 25, 2025):

把http2https改成https2https就可以了

@yogaxu commented on GitHub (Nov 25, 2025): 把http2https改成https2https就可以了
