[PR #245] [MERGED] Fix non-standard volume/brightness scales not working properly #1076

New issue

Closed

opened 2026-05-05 07:04:04 -06:00 by gitea-mirror · 0 comments

gitea-mirror commented

2026-05-05 07:04:04 -06:00

Owner

📋 Pull Request Information

Original PR: https://github.com/MonitorControl/MonitorControl/pull/245
Author: @victorchabbert
Created: 6/22/2020
Status: ✅ Merged
Merged: 9/20/2020
Merged by: @JoniVR

Base: master ← Head: master

📝 Commits (1)

6f3196a Refactor calcNewValue

📊 Changes

6 files changed (+78 additions, -30 deletions)

View changed files

📝 MonitorControl.xcodeproj/project.pbxproj (+4 -0)
📝 MonitorControl/Info.plist (+1 -1)
📝 MonitorControl/Model/Display.swift (+22 -8)
📝 MonitorControl/Model/ExternalDisplay.swift (+25 -20)
➕ MonitorControl/Support/OSDUtils.swift (+25 -0)
📝 MonitorControlHelper/Info.plist (+1 -1)

📄 Description

Previously, calcNewValue assumed your display's maxValue was a 100.
This caused the OSD to block after certain values (see #201).
It also tried to find the "prettiest" monitor value to display during
normal increments.

This PR refactors the calcNewValue function to focus on finding the next value based on the monitor's value scale.
Behaviour:

Get the corresponding chiclet value based on the monitor value.
Calculate the distance between the nearest whole chiclet and the chiclet
from the monitor value
Depending on the direction (up or down) and if the distance is between
a set threshold, we jump to the next chiclet skipping the nearest.
Otherwise, we go to the nearest chiclet.

calcNewValue no longer tries to find the "prettiest" value as we round the chiclets during normal increments and use the chiclet scale (x/16).

QA

closes #201

_{🔄 This issue represents a GitHub Pull Request. It cannot be merged through Gitea due to API limitations.}
